Bauer ring is a new type of packing, is the 1940s German BASF company in the Rasi ring on the relatively large improvements made, it is made of sheet metal punching and zipping, although the ring outer diameter is also equal to the height, but the ring wall open two rows of windows with inwardly extending tongues, each layer of window holes with five tongues, pointing to the center of the ring, in the center of the almost lap, the upper and lower two layers of the window holes in the position of each other staggered, the general openings in the total area of about For the whole ring area of about 35%. This structure improves the gas-liquid distribution, making full use of the inner surface of the ring can be fully utilized.

Characteristics of ceramic Bauer ring packing:

Due to the relationship between the structure of the Bauer ring, the ring wall openings, greatly improving the utilization rate of the ring space and the inner surface of the ring, the air resistance is small, the liquid distribution is uniform. Has the advantages of large flux, low resistance, high separation efficiency and operational flexibility, etc., in the same buck, the handling capacity can be larger than the Lassie ring more than 50%. Compared with the Lacy ring, this packing has a large production capacity, strong resistance, operational flexibility and other characteristics, in general the same pressure drop when handling can be 50% -100% larger than the Lacy ring, the same processing pressure drop than the Lacy ring is smaller than 50% -70%, the gas flux of the Bauer ring can be increased by more than 50%, the efficiency of the mass transfer equipment to improve the efficiency of about 30%. Bauer ring material is generally ceramic, metal, plastic

Application of ceramic Bauer ring packing:

Bauer ring is a widely used packing:

Plastic Bauer ring packing is especially suitable for petroleum, chemical, chlor-alkali, gas, environmental protection and other industries in the low and medium temperature (60-150 degrees) distillation, absorption and scrubbing towers and carbon dioxide degassing tower, ozone contact reflective tower as a contact packing and other reaction towers.

Ceramic Bauer ring packing is suitable for carbon dioxide degassing tower acid mist purification tower, ozone contact reaction tower as contact packing and other reaction tower.

Metal Bauer ring packing application: vacuum distillation tower, dealing with heat-sensitive, easy to decompose, easy to polymerize, easy to carbonize materials.

Specification parameters of ceramic Bauer ring packing:
