All-ceramic high-efficiency regular packing is a new type of high-efficiency packing, now widely used in petroleum, coking, power generation, fertilizer, ammonia and other coal chemical and fine chemical industries. Practically used in coking desulfurization, benzene washing, naphthalene washing, ammonia washing tower, chemical fertilizer hot water saturation tower, power plant shower cooling tower, sulfuric acid drying tower, absorption tower. This series of packing has the advantages of large specific surface area, high void rate, large mass transfer coefficient, anti-clogging, corrosion resistance, resistance to rapid cold and heat, long service life, easy to install, and is an ideal tower packing. Our company can process and produce “light” ceramic packing and “full” ceramic packing according to the different requirements of users for materials. To meet the needs of the continuous development of the market.

All-ceramic high-efficiency regular packing has the following detailed characteristics:

1、All-ceramic high-efficiency regular packing has light specific gravity and small resistance.

2, all-ceramic high-efficiency regular packing mass transfer coefficient is large, the effective area is large, and the effect is good.

3, the whole porcelain combination packing aging resistance, strong corrosion resistance, long service life

4, all-porcelain high-efficiency regular packing structure is novel, can be cut, easy to load

First, all-ceramic high-efficiency regular packing stacking density, high void rate, low resistance

    New all-ceramic high-efficiency regular packing bulk density of 2.3 ~ 2.6g/cm3, packing density of 0.32 ~ 0.48g/cm3, the product stacking void rate of up to 72% -80%, so that the packing tower has a light weight, small load, low operating resistance, pressure reduction advantages.

Second, all-ceramic high-efficiency regular packing mass transfer coefficient, large effective area, good results

　 Through the Tianjin University of all-ceramic high-efficiency regular packing performance measurement shows that the product mass transfer coefficient is large, is generally two times the ceramic packing. Packing in the filling after its neighboring packing only 6 support legs overlap for the invalid area, and gas-liquid phase transfer form is 'face' contact, coupled with the packing system honeycomb hole structure ceramics, has a high spatial circulation area, thus making the effective area of the packing is greater than 98.5%, separation and purification effect is excellent.

Third, the all-ceramic high-efficiency regular packing aging resistance, strong corrosion resistance, long service life

　　The new all-ceramic high-efficiency regular packing has good heat resistance, fire resistance up to 1400 ℃, and resistance to rapid cold and heat, acid and alkali resistance, long service life, not easy to aging. Compared with it, the cost of plastic filler is low, but the weakness of plastic filler is not temperature resistance, easy to aging, short service life, and carbon steel metal filler is not suitable for corrosive media occasions, if changed to stainless steel metal filler is expensive.

Fourth, the new all-ceramic high-efficiency regular filler structure is novel, can be cut, easy to load

　  New all-ceramic high-efficiency regular packing can be cut and assembled into a circle, not only easy to fill, but also to make the whole filling plane is 100% utilization, other regular packing due to the non-cutting, the tower inevitably around the size of the cavity, wall flow, ditch flow phenomenon is serious, to varying degrees, will affect the effectiveness of the use.

   The new all-ceramic high-efficiency regular packing has successfully solved the contradiction between the void rate and the specific surface area, which is not easy to block the tower and the use of good results, is the best choice for users of the packing tower.
